Fabric Laser Cutter with Auto Feeding System/Auto Fabric Feeding Cutting Machine for Sale

Product Description

      Product Description    Fabric Laser Cutter with Auto Feeding System Nonwoven Fabric Cutting Machine
    Main Features 1.The automatic feeding system is added to save time and cost, and to improve work efficiency.
2.Crawler correction device can prevent crawler belt dislocation when working.
3.Cloth auto-collecting device is very convenient for users to collect cloth.
4.Multi-layer feeding device is already for users to process multi-layer cloth at the same time.
5.To meet the demand of cutting in large width, Vmade laser cutting machine bed adopts the machine
tool-level chassis to ensure the stability and accuracy in high speed working. 6. The moving system adopts Taiwan Hiwin linear guide and precision gear, matched up with the
advanced DSP-controlled 3-phase stepper motor to ensure the working accuracy.
6.News-style high-efficiency laser tube is adopted. Laser beam is more stable than the traditional
type. Usage age is more than 10000 hours. Technical Parameter

Model

 VML1325A

VML1610A

Option

Working Area

 1600*3000mm

1800*3000mm

According to

Demands

Laser Power

 60w/80w / 100w / 130w / 150w

Laser Type

 CO2 Sealed Laser Tube,10.6μm

Cooling Type

 Water Cooling

Cutting Speed

 0—30000mm/min

Laser Output Control

 0—100% Software Setting

Smallest Character Engraving

 2.0*2.0mm1.0*1.0mm / English 1.0mm*1.0mm

Highest Scanning Precision

 4000DPI

Locating Precision

 ≤+0.01mm

Controlling Software

 DSP Control System

Graphic Format Supported

 DST PLT BMP DXF DWG AI LAS,etc

Compatible Software

 TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All type of

AUTOCAD  Software in Cloth

Color Separation

 Yes

Drive System

 High-precision 3-phase Stepper Motor

Auxiliary Equipments

 Exhaust Fan and Air Exhaust Pipe

Power Supply

 AC110V/220V+10%,50HZ/60HZ

  Applications Garments sampling, large format tailoring ,leather  industry ,shoemaking ,decoration,furniture ,advertisement, packing and printing ,molding and art crafts  industries,etc.  Applicable Materials Fabrics,cloth, laser, paper, bamboo ware, acrylic, glass, thin film and canvas, etc.   Packaging & Shipping 15working days for shipment wooden packaging  with  ship and  planes     contact details   Welcom to visit our factory If you have any questions, Please contact us

Contact us if you need more details on Auto Feeding Fabric Cutting Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Fabric Laser Cutter with Auto Feeding System、Fabric Laser Cutter with Auto Feeding System\/ Fabric Cutting Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
