Hot Sale 30 W Economical Fiber Laser Marker /Laser Marking Machine for Stainless Steels Metals ABS Plastics

Product Description

Product Description Hot Sale 30 W  Economical Fiber Laser Marker /Laser Marking Machine for Stainless Steels Metals ABS Plastics Relation Products
Fiber Laser Marking Machine        CNC router Machine           Plasma Cutting Machine
Product features  1.Marking for many type metals and some nonmetallic material2.70*70mm 110*110mm,160*160mm Marking Area Optional 3.10W 20W 30W laser power optional 4.Desktop or Hand-held model Optional   Most advanced New style fiber laser marking machine is the 3th-generation laser marking machine which is manufactured by the most advanced laser technology in current of the world. Fastest marking   With high repeat of the pulse,power outputsteadily,energy surge of single pulse is lower than 1%,can achieve high speed marking,and control the depth and shape of the facu The processing speed is 2-3 times than the traditional marking machine.   Compact The size of the macine is very small, portable, suitable for both  mobile and fixed working.   10 years life,ultra-low running cost  Long life,ultra-low power consumption,the conversion efficiency is more than 30%,  the unit power of the machine is no more than 0.5kw.   Wide range of application   The machine can marking on all themetal materials and some of nonmetal materials.     Easily Operating   Afford the specific marking software based on Windows, which is real-time adjust the laser power and pulse frequency. You can input and output by computer according to edit in the both of the specific marking software and the graphic software such as AutoCAD, CorelDRAW or Photoshop.   Machine Parameter Specification

Model

VLM 10F/20F/30F

Laser power

10W/20W/30W

Laser Wavelength

1065±10nm

Q-frequency

20KHz~100KHz

Divergence

0.3mard

Marking range

110*110mm/205*205mm/290*290mm

Minimum line width

0.01mm

Minimum character

0.1mm

Marking speed

7000mm/s

Marking depth

0 ~0.5mm

Engraving line speed

≤7000mm/s

Repeatability accuracy

±0.001mm

Beam quality

M2:1.2~1.8

Marking Format

Graphics, text, bar codes, two-dimensional code, automatically

marking the date, batch number, serial number, frequency,etc.

Graphic format supported

bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc.

working voltage

220V±10%/50Hz/4A

Unit power

<0.5kw

Working environment

Clean and dust free or dust less

Workingcondition:Humidity

5%-75%,free of condensed water

Laser module life

>100000 hours

Net weight

35kg

Packing size

0.77*0.25*0.6m

Composition       Applicable Materials Metals (including rare metals), engineering plastics, electroplating materials, coating materials,coating   materials, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel, titanium, copper and other materials  Samples Packaging & Shipping 5-7 working days for shipment wooden packaging  with  ship and  planes       Our Services One year warranty for the whole machine. Teach video and detailed manual sent with the machine. 24 hours online support. Professional technical support Free design and guide for customer Free software update We can supply the new machine parts or fix the old one. Company Information Jinan Vmade CNC Machine Co.,Ltd was established in 2010. Located in high-tech zone, Jinan City,
Shandong Province of China.
It is a professional team which specialized in Optic, Electricity, Mechanics, and R&D field. Vmade keep  delicate andattentive attitude on every step and always keep to learn the most advanced technology and create more humanized products to all our customers.   contact details           We are a big family~Welcome to join us
