Birds rings engraving machine for fiber laser marking 20w 30W for Sale
Product Description
Product Description Birds rings engraving machine for fiber laser marking 20w 30W for Sale
Marking for many type metals and some nonmetallic material 70*70mm 110*110mm,160*160mm Marking Area Optional 10W 20W 30W laser power optional Desktop or Hand-held model Optional
Product features Most advanced. New style Fiber Laser Marking Machine is the 3th-generation Laser Marking Machine which is manufactured by the most advanced laser technology in current of the world. Delicate marking. The quality of laser beam is very good (near to the limit of diffraction,eporting TEM00 fundamental transverse mode,M2 near to 1,expanding of laser beam is only 1/4 of the diode laser marker),therefore it is very suitable for delicate marking. Fastest marking. With high repeat of the pulse,power outputsteadily,energy surge of single pulse is lower than 1%,can achieve high speed marking,and control the depth and shape of the facula. The processing speed is 2-3 times than the traditional marking machine. Compact. The size of the macine is very small, portable, suitable for both mobile and fixed working. 10 years life,ultra-low running cost. Long life,ultra-low power consumption,the conversion efficiency is more than 30%,the unit power of the machine is no more than 0.5kw. Wide range of application.The machine can marking on all themetal materials and some of nonmetal materials. Easily Operating: Afford the specific marking software based on Windows, which is real-time adjust the laser power and pulse frequency. You can input and output by computer according to edit in the both of the specific marking software and the graphic software such as AutoCAD, CorelDRAW or Photoshop. Machine Parameter Specification
Sample
Samples
Applicable Materials Metals (including rare metals), engineering plastics, electroplating materials, coating materials,coating materials, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel, titanium, copper and other materials Packaging & Shipping 5-7 working days for shipment wooden packaging with ship and planes
Our Services One year warranty for the whole machine. Teach video and detailed manual sent with the machine. 24 hours online support. Professional technical support Free design and guide for customer Free software update We can supply the new machine parts or fix the old one. Company Information Jinan Vmade CNC Machine Co.,Ltd was established in 2010. Located in high-tech zone, Jinan City,
Shandong Province of China.
It is a professional team which specialized in Optic, Electricity, Mechanics, and R&D field. Vmade keep delicate and attentive attitude on every step and always keep to learn the most advanced technology and create more humanized products to all our customers.
contact details A big family We are waiting for you Welcome to join us
Contact us if you need more details on 20w Birds leg rings fiber laser engraving machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about bird ring\/pigeon ring laser marking \/20w fiber laser marking machine、20w fiber laser marking machine Price. If these products fail to match your need, please contact us and we would like to provide relevant information.
Marking for many type metals and some nonmetallic material 70*70mm 110*110mm,160*160mm Marking Area Optional 10W 20W 30W laser power optional Desktop or Hand-held model Optional
| product details |
Product features Most advanced. New style Fiber Laser Marking Machine is the 3th-generation Laser Marking Machine which is manufactured by the most advanced laser technology in current of the world. Delicate marking. The quality of laser beam is very good (near to the limit of diffraction,eporting TEM00 fundamental transverse mode,M2 near to 1,expanding of laser beam is only 1/4 of the diode laser marker),therefore it is very suitable for delicate marking. Fastest marking. With high repeat of the pulse,power outputsteadily,energy surge of single pulse is lower than 1%,can achieve high speed marking,and control the depth and shape of the facula. The processing speed is 2-3 times than the traditional marking machine. Compact. The size of the macine is very small, portable, suitable for both mobile and fixed working. 10 years life,ultra-low running cost. Long life,ultra-low power consumption,the conversion efficiency is more than 30%,the unit power of the machine is no more than 0.5kw. Wide range of application.The machine can marking on all themetal materials and some of nonmetal materials. Easily Operating: Afford the specific marking software based on Windows, which is real-time adjust the laser power and pulse frequency. You can input and output by computer according to edit in the both of the specific marking software and the graphic software such as AutoCAD, CorelDRAW or Photoshop. Machine Parameter Specification
Model | ELM10F/20F/30F |
Laser power | 10W/20W/30W |
Laser Wavelength | 1065±10nm |
Q-frequency | 20KHz~100KHz |
Divergence | 0.3mard |
Marking range | 110*110mm/205*205mm/290*290mm |
Minimum line width | 0.01mm |
Minimum character | 0.1mm |
Marking speed | 7000mm/s |
Marking depth | 0 ~0.5mm |
Engraving line speed | ≤7000mm/s |
Repeatability accuracy | ±0.001mm |
Beam quality | M2:1.2~1.8 |
Marking Format | Graphics, text, bar codes, two-dimensional code, automatically marking the date, batch number, serial number, frequency,etc. |
Graphic format supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. |
working voltage | 220V±10%/50Hz/4A |
Unit power | <0.5kw |
Working environment | Clean and dust free or dust less |
Workingcondition:Humidity | 5%-75%,free of condensed water |
Laser module life | >100000 hours |
Net weight | 35kg |
Packing size | 0.77*0.25*0.6m |
Samples
Applicable Materials Metals (including rare metals), engineering plastics, electroplating materials, coating materials,coating materials, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel, titanium, copper and other materials Packaging & Shipping 5-7 working days for shipment wooden packaging with ship and planes
Our Services One year warranty for the whole machine. Teach video and detailed manual sent with the machine. 24 hours online support. Professional technical support Free design and guide for customer Free software update We can supply the new machine parts or fix the old one. Company Information Jinan Vmade CNC Machine Co.,Ltd was established in 2010. Located in high-tech zone, Jinan City, Shandong Province of China.
It is a professional team which specialized in Optic, Electricity, Mechanics, and R&D field. Vmade keep delicate and attentive attitude on every step and always keep to learn the most advanced technology and create more humanized products to all our customers.
contact details A big family We are waiting for you Welcome to join us
Contact us if you need more details on 20w Birds leg rings fiber laser engraving machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about bird ring\/pigeon ring laser marking \/20w fiber laser marking machine、20w fiber laser marking machine Price. If these products fail to match your need, please contact us and we would like to provide relevant information.
