VIN Code Serial Numbers/ Metal Pneumatic Pin Hand-held Dot Peen Marking Machine for Touch Screen Operation

Product Description

VIN Code Serial Numbers/ Metal Pneumatic Pin Hand-held Dot Peen Marking Machine for Touch Screen Operation Product Description   Feature   VMADE VMD-B series dot peen marking machine is the pneumatic marking machine,.It works by compressed air. It can mark signs, characters and pictures on various kinds of hard materials such as mental and plastic. It featured with distinct and beautiful effect, editable contents, adjustable sign size,depth, and high speed,   Technical Parameter

Type Number

VPM0212A/20208

Marking Range

20mm×120mm (Size can be
customized according to the user)

Marking speed range:

10~100 words/min (characters)

Marking depth range

0.05 ~ 1.0mm (according to materials )

Compressed air pressure
 required

0.4~0.8Mpa

System functions

1.Character input, editing, marking

2.VIN code automatically calculated,
set, mark
ing

3.Serial number setting, automatically
increase, marking

4.Tag data query, reporting, print

5.Characters, graphics, Chinese character editing

Marked Font size

Arbitrary adjustable

Tag character content

0 ~ 9 figures, A ~ Z large, lowercase letters Graphics,
 characters (users can be random homemade)

Operating voltage

Control cabinet ~ 220V 50Hz ± 10%

Machine power:

200W

Work Environment

Temperature: 5 ~ +35 C ° Humidity: ≤ 80% room

Safety



Insulation resistance:Normal atmospheric
pressure≥5MΩ/500V

Electric strength: 50Hz1500V 1min

Leakage Current

≤0.75Ma

  Samples       Packaging & Shipping 5-7 working days for shipment wooden packaging  with  ship and  planes
  After-Sales Service
contact details Please tell us what you need
1.What is your working size?
2.What material do you need to cut/engrave?
3. What is the thickness and size of each materials?
4.What is your business industry? signage or art craft works or what else ?
5.What is your full name,email,company name,website and contact number ? If you have any questions, Please contact us


Contact us if you need more details on Pneumatic Pin Marking Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Characters Letters VIN Code Dot Peen Marking Machine、Hand-held Pin Marking Machine For VIN Code. If these products fail to match your need, please contact us and we would like to provide relevant information.
